STE2 R2 Environment Monitors with Sensor Pack
Price includes a 3m temperature sensor.
Extra Services: Installation and Support Plans.
Lead Times & Delivery Guide – contact us for a specific day/time
Our Price Check Guarantee ensures value for money when buying this product
Pay using our secure payment gateway with a debit/credit card, your Amazon, Google or PayPal account, make a BACS payment, open a credit account or request a leasing quotation.
STE2 R2 Environment Monitors are designed to measure temperature and humidity values through connected sensors and can be monitored via an Ethernet or WiFi connection over a local area network using HWg-PDMS software or over the internet via the HWg Cloud or SensDesk Cloud portals or SensDesk Mobile App (iOS or Android).
The device can connect up to five sensor inputs via 1-Wire and 1-Wire UNI and up to two detectors via Digital Inputs (DI) using dry signal contacts. The device can be powered via a power adaptor or PoE (Power over Ethernet). The STE2 R2 supports SNMP and will issue alarm signals when the measured values exceed pre-set points via email. SMS text messages can also be sent via the portals to an ‘email to text’ service or using SMS GW3 Gateway on the same Ethernet/IP network.
STE2 R2 Kits
| Kits | Content |
|---|---|
| STE2-R2 | Unit, Temperature sensor (3m) and 5Vdc power adapter |
| STE2-R2-THSET | Unit, Temperature & Humidity sensor (3m) and 5Vdc power adapter |
| STE2-R2-THSWET | Unit, Temperature & Humidity sensor (3m), Spot water detector (3m) and 5Vdc power adapter |
Other sensors can be connected as required in place of the sensors(s) supplied in the kits.
Key Features
- Monitoring over Ethernet and WiFi
- Five 1-Wire Inputs for Sensors (on 2 physical ports) and two Digital Inputs for Detectors
- HTTP and HTTPS web interface
- Alarm alerts by e-mail and text messages (SMS), STE2 R2 also includes the option to dial the target number (requires external gateway)
- 5Vdc power supply or Power over Ethernet (PoE)
- M2M communication protocols: SNMP and XML
- Connects to an Ethernet LAN and configured via a built-in web server
- NMS connectivity (SNMP v1 MIB) and supports DHCP
- Logged data can be exported to Microsoft Excel using HWg-PDMS software
- Compatible with a range of third party software packages using Borland C++, MS Visual, VB, C#, PHP, JAVA and more
Applications
- Monitoring for air conditioning system failures
- Heating system monitoring and optimisation
- Cooler systems, fridges and freezers monitoring
- Remote server rack temperature monitoring
1-Wire Temperature Sensors
- Temp-1Wire IP67 (3m included)
- Temp-1Wire-Flat 3m
- Temp 1Wire Pt1000 Cable3
- Temp-1Wire 3m calibrated
- Temp-1Wire Rack 19
- Temp-1Wire-Outdoor 3m
1-Wire Humidity Sensors
1-Wire Temperature and Humidity Sensors
Water Leakage Detectors
Detectors
- Air Flow sensor 5101
- Door contact detector MK4
- Gas Leak detectors
- Motion PIR detectors
- Optical Smoke detector FDR26
- Power detectors
- Vibration detector SS14
Air Quality Sensors
- Carbon Dioxide (CO2) and Humidity levels
- Volatile Organic Compounds (VOC), Temperature, Humidity and Atmospheric Pressure levels
Physical Installation
- Plastic Case: IP40
- Installation: DIN, wall, flat surface, rack shelf
- Design: SoHo, IT
Operation Schematic
Internet of Things (IoT) Applications
STE2 R2 is ideal for IoT applications and provides data transfer via Ethernet or WiFi. The HWg Cloud and SensDesk portals provide a quick view of the recorded data (up to 3 months) which can also be viewed on the SensDesk mobile application. Data can be sent via email, custom software or third-party Cloud applications using TCP and SNMP protocols. IoT PDMS software allows the data to be converted to Excel format for further analysis. Using SNMP support, STE2 logged data can be accessed via third-party IoT portals with data recorded in real-time and timestamped.
See the features and protocols comparison table to compare this product to similar environmental monitoring devices.
